SC-PE615
Active Horn Speaker
The SC-PE615 is a compact, highly intelligible speaker with a built-in 10W power amplifier powered by PoE+ and DC input, that provides public address announcement and remote paging via network video surveillance applications. Its rugged enclosure is IP66 rated for outdoor environments.
•For public address announcements and remote paging.
•A compact and highly intelligible speaker.
•Built-in 10W power amplifier powered by PoE+ and DC input.
•IP66 rated for outdoor environments.
- Specifications
- Downloads
Specifications
Specifications for product:
| SC-PE615 | |
|---|---|
| Power source |
PoE (IEEE802.3af Class 3) or PoE+ or DC12V/ DC24V (9V-29V) |
| Power / current consumption |
35 W or less (Rated output) 4 W or less (Standby) |
| Frequency response |
280 Hz - 12 kHz |
| Rated output |
7.5W (at DC12V powered) 10W (at PoE+ powered) 5W (at PoE powered)
|
| Sensitivity (1 W, 1 m) |
105 dB |
| Max. SPL (1 m) |
115 dB |
| Audio input |
-6dB, 10kΩ electronically-balanced, removeable terminal block (3 pins) |
| Speaker output |
Low impedance (8Ω) |
| Operating temperature |
-20º ~ +50ºC |
| Finish |
Aluminium, off-white |
| Dimensions |
222 x 162 x 281 mm (W x H x D) |
| Weight |
1.35 kg |
