F-1000BTWP EB-Q
Design Speakers
- 2-way speaker with high quality 10 cm woofer and balanced dome tweeter
- Octagonal horn for clear, wide-area sound coverage 90° x 90°
- Wall-mount pan-tilt bracket included
- Easy impedance selection by rotary switch
- Paintable
- Certified according to EN 54-24
- Specifications
- Application examples
- Equipment
- Tender text
- Downloads
Specifications
Specifications for product:
| F-1000BTWP EB-Q | F-1000BTWP EB-Q | F-1000WTWP EB-Q | F-1000WTWP EB-Q | F-2000BTWP EB-Q | F-2000BTWP EB-Q | F-1300BTWP EB-Q | F-1300BTWP EB-Q | F-1300WTWP | F-1300WTWP EB-Q | |
|---|---|---|---|---|---|---|---|---|---|---|
| Frequency response |
85 Hz - 20 kHz |
85 Hz - 20 kHz |
85 Hz - 20 kHz |
85 Hz - 20 kHz |
65 Hz - 20 kHz |
65 Hz - 20 kHz |
80 Hz - 20 kHz |
80 Hz - 20 kHz |
80 Hz - 20 kHz |
80 Hz - 20 kHz |
| Sensitivity (1 W, 1 m) |
87 dB |
87 dB |
87 dB |
87 dB |
92 dB |
92 dB |
90 dB |
90 dB |
90 dB |
90 dB |
| Rated input (100 V) |
15 W |
15 W |
15 W |
15 W |
60 W |
60 W |
30 W |
30 W |
30 W |
30 W |
| Tappings (100 V) |
100 V : 670 Ω (15 W) / 1 kΩ (10 W) / 2 kΩ (5 W) / 3.3 kΩ (3 W) / 10kΩ (1 W) 70 V : 330 Ω (15 W) / 670 Ω (7.5 W) / 2 kΩ (2.5 W) / 3.3 kΩ (1.5 W) / 10kΩ (0.5 W) |
100 V : 670 Ω (15 W) / 1 kΩ (10 W) / 2 kΩ (5 W) / 3.3 kΩ (3 W) / 10kΩ (1 W) 70 V : 330 Ω (15 W) / 670 Ω (7.5 W) / 2 kΩ (2.5 W) / 3.3 kΩ (1.5 W) / 10kΩ (0.5 W) |
100 V : 670 Ω (15 W) / 1 kΩ (10 W) / 2 kΩ (5 W) / 3.3 kΩ (3 W) / 10kΩ (1 W) 70 V : 330 Ω (15 W) / 670 Ω (7.5 W) / 2 kΩ (2.5 W) / 3.3 kΩ (1.5 W) / 10kΩ (0.5 W) |
100 V : 670 Ω (15 W) / 1 kΩ (10 W) / 2 kΩ (5 W) / 3.3 kΩ (3 W) / 10kΩ (1 W) 70 V : 330 Ω (15 W) / 670 Ω (7.5 W) / 2 kΩ (2.5 W) / 3.3 kΩ (1.5 W) / 10kΩ (0.5 W) |
100 V : 170 Ω (60 W) / 330 Ω (30 W) / 670 Ω (15 W) / 3.3 kΩ (3 W) 70 V : 83 Ω (60 W) /170 Ω (30 W) / 330 Ω (15 W) / 670 Ω (7.5 W) / 3.3 kΩ (1.5 W) |
100 V : 170 Ω (60 W) / 330 Ω (30 W) / 670 Ω (15 W) / 3.3 kΩ (3 W) 70 V : 83 Ω (60 W) /170 Ω (30 W) / 330 Ω (15 W) / 670 Ω (7.5 W) / 3.3 kΩ (1.5 W) |
100 V : 330 Ω (30 W) / 1 kΩ (10 W) / 3.3 kΩ (3 W) / 10 kΩ (1 W) 70 V : 170 Ω (30 W) / 330 Ω (15 W) / 1 kΩ (5 W) / 3.3 kΩ (1.5 W) / 10 kΩ (0.5 W) |
100 V : 330 Ω (30 W) / 1 kΩ (10 W) / 3.3 kΩ (3 W) / 10 kΩ (1 W) 70 V : 170 Ω (30 W) / 330 Ω (15 W) / 1 kΩ (5 W) / 3.3 kΩ (1.5 W) / 10 kΩ (0.5 W) |
100 V : 330 Ω (30 W) / 1 kΩ (10 W) / 3.3 kΩ (3 W) / 10 kΩ (1 W) 70 V : 170 Ω (30 W) / 330 Ω (15 W) / 1 kΩ (5 W) / 3.3 kΩ (1.5 W) / 10 kΩ (0.5 W) |
100 V : 330 Ω (30 W) / 1 kΩ (10 W) / 3.3 kΩ (3 W) / 10 kΩ (1 W) 70 V : 170 Ω (30 W) / 330 Ω (15 W) / 1 kΩ (5 W) / 3.3 kΩ (1.5 W) / 10 kΩ (0.5 W) |
| Speaker component |
Woofer: 10 cm cone-type Tweeter: balanced dome-type |
Woofer: 10 cm cone-type Tweeter: balanced dome-type |
Woofer: 10 cm cone-type Tweeter: balanced dome-type |
Woofer: 10 cm cone-type Tweeter: balanced dome-type |
Woofer: 20 cm cone-type Tweeter: 25 mm dome-type |
Woofer: 20 cm cone-type Tweeter: 25 mm dome-type |
Woofer: 13 cm (5'') cone-type Tweeter: 25 mm (1'') dome tweeter |
Woofer: 13 cm (5'') cone-type Tweeter: 25 mm (1'') dome tweeter |
Woofer: 13 cm (5'') cone-type Tweeter: 25 mm (1'') dome tweeter |
Woofer: 13 cm (5'') cone-type Tweeter: 25 mm (1'') dome tweeter |
| Rated impedance (low impedance) |
8 Ω |
|||||||||
| Crossover frequency |
5000 Hz |
5000 Hz |
5000 Hz |
5000 Hz |
2500 Hz |
2500 Hz |
2000 Hz |
2000 Hz |
2000 Hz |
2000 Hz |
| Dimensions |
130 x 202 x 131 mm (W x H x D) |
130 x 202 x 131 mm (W x H x D) |
130 x 202 x 131 mm (W x H x D) |
130 x 202 x 131 mm (W x H x D) |
244 x 373 x 235 mm (W x H x D) |
244 x 373 x 235 mm (W x H x D) |
162 x 250 x 161 mm (W x H x D) |
162 x 250 x 161 mm (W x H x D) |
162 x 250 x 161 mm (W x H x D) |
162 x 250 x 161 mm (W x H x D) |
| Finish |
HIPS resin, Steel plate, black (RAL 9011 or equivalent) |
HIPS resin, Steel plate, black (RAL 9011 or equivalent) |
HIPS resin, Steel plate, off-white (RAL 9010 or equivalent) |
HIPS resin, Steel plate, off-white (RAL 9010 or equivalent) |
HIPS resin, Steel plate, black (RAL 9011 or equivalent) |
HIPS resin, Steel plate, black (RAL 9011 or equivalent) |
HIPS resin, Steel plate, black (RAL 9011 or equivalent) |
HIPS resin, Steel plate, black (RAL 9011 or equivalent) |
HIPS resin, Steel plate, off-white (RAL 9010 or equivalent) |
HIPS resin, Steel plate, off-white (RAL 9010 or equivalent) |
| Operating temperature |
-10°C to + 50°C |
-10°C to + 50°C |
-10°C to + 50°C |
-10°C to + 50°C |
-10°C to + 50°C |
-10°C to + 50°C |
-10°C to + 50°C |
-10°C to + 50°C |
-10°C to + 50°C |
-10°C to + 50°C |
| Weight |
2 kg |
2 kg |
2 kg |
2 kg |
7.4 kg |
7.4 kg |
3.6 kg |
3.6 kg |
3.6 kg |
3.6 kg |
